Overview
Theory:
Output:
Color:
Details
Rating :
♦ Rated zero-power resistance R25 : 10kΩ ±1% (at 25℃)
♦ B value. B25/85 : 3,435K ±1 %
*The B value is calculated using the zero-power resistance values measured at 25℃ and
85℃.
♦ Dissipation factor. :Approx. 0.7 mW/℃(in still air)
♦ Thermal time constant. :Approx. 3 s (in still air)
♦ Maximum power rating. : 3.5 mW (at 25℃)
♦ Operating temperature range : -30 ~ 90 ℃
Climatic Test :
♦ Dry heat : 90+/- 2°C * 1000 HRS (in air)
♦ Damp heat : 40+/- 2°C * 1000 HRS (in the humidity of 95%)
♦ Cold : -30+/- 3°C* 1000 HRS
