KST820-16
Overview
This type thermostat, regulator is widely applicable for Electric Oven, Electric Fryer, Electric Pressure Cooker and various Electric Heating Equipment etc.
Details
Working Principle:
Being used the bimetal as temperature response element. It can be deformed when the bimetal reach a definite temperature. Trip of bimetal can separate the contactor quickly and cuts off the power. The reset of bimetal can switch on the power when the temperature decreased to the original level. Adjusting the screw bolt to push the spring can adjust the different working temperature of appliances. ac thermostat, mechanical thermostat
Specification:
Electrical Ratings: AC 250V/12A, AC125V/15A
Temperature Setting Range: 0~300 ºC
Max Service Temperature: 300 ºC (Designed by user’s requirements)
Temperature Tolerance: ±5 ºC%
Reset Temperature: 5 ºC -30 ºC
Life Cycle: No less than 100,000 times
Temperature Setting Range: 0~300 ºC
Max Service Temperature: 300 ºC (Designed by user’s requirements)
Temperature Tolerance: ±5 ºC%
Reset Temperature: 5 ºC -30 ºC
Life Cycle: No less than 100,000 times
