Overview
Application:
Very suitable for fire alarm system
Very suitable for fire alarm system
Details
* CONTACT TYPE : Normally Closed
* ACTION TEMP : 57 °C ± 3 ℃
* RESET TEMP : 37 °C ± 4 ℃
* TERMINAL SIZE : Amp #1004 TAB
* CIRCUIT RESISTANCE : 50m MAX.
* INSULATION RESISTANCE : 100M min. at DC 500V
* DIELECTRIC STRENGTH : AC 1500V For One Minute
Or AC 1800V For One Sec
*APPROVALS AND OPERATING LIFE :
UL CUL:100,000 Cycles :15A 125VAC/10A 250VAC
ENEC17:100,000 Cycles :15A 125VAC/10A 250VAC
10,000 Cycles :16A 250VAC
CQC:10,000 Cycles :16A 250VAC
